AKM 115S F152

How energy efficiency is improved

Automatic adaptation to ball valve, electronic cut-off, precise activation and high energy efficiency with minimal operating noise

Features

• For operating 2- and 3-way ball valves VKR, VKRA, BKR, BKRA, VKAI, VKAA, BKLI, BKTI, BKTA and 6-way ball valve B2KL
• For controllers with constant output (0…10 V/4…20 mA) or switching output (2-/3-point control)
• Assembly with ball valve without the use of tools
• Brushless motor with electronic activation and cut-out
• Intelligent adaptation of rotation angle, incl. feedback adjustment
• Electronic force-dependent cut-off
• Direction of rotation selected with DIP switch
• Pulse length correction in 3-point operation, i.e. internal adjustment of start-up time
• Gear unit can be disengaged in order to position the ball valve manually (using the lever)
• Maintenance-free
• Free configuration using the CASE Drive PC tool
• Bracket and bayonet ring made of glass-fibre-reinforced plastic for fitting onto ball valve
