FMS 116, 117, 196, 197

How energy efficiency is improved

Smart multi-sensors in a mesh network for recording movement/presence, brightness, temperature, humidity, air quality and sound pressure levels in rooms or room zones for energy-optimising room automation and for good, pleasant room air.

Features

• Measurement of indoor air quality (IAQ), such as temperature, humidity and air quality (VOC, CO2:).
• Measurement of indoor environment quality (IEQ), such as motion/presence, brightness and sound pressure level
• Sensor values can be used for more precise information on the state of the room (sensor fusion)
• For ceiling mounting (recessed/surface-mounted)
• Minimal sensor wiring thanks to Bluetooth® Mesh network
• Controllable coloured LED ring for displaying the room status to room users
• Parameterisable animation profiles for LED ring, e.g. room reserved/available, room air quality good/bad, room ready for cleaning, etc.)
• Bluetooth Beacon function for locating the room user with a smartphone and optimised use of SAUTER Mobile Building Services (Mobile Room Control app)
• IoT ready thanks to encrypted MQTT communication as MQTT client of FMS 19x sensor gateway
• For up to 16 sensors for an ecos504/505 room controller
• Simple integration into the SAUTER automation system with the FMS 19x sensor gateway thanks to CASE Suite and Bluetooth smartphone app
• Meshing of up to 15 FMS 116, 117 sensors via Bluetooth mesh technology to the FMS 19x sensor gateway
